142
BoomLiftModels X20JPLUS
MAINTENANCE
MUX20JP021602
12.1.2.Greasingpoints
12.1.3.Greasingthetelescopicboom
Fig.151 Greasingpointsdiagram
Respectthegreasingintervalsindicatedanduseonlytherecommendedlu‐
bricantsinordertoprotectpinsandconnectionsfromwear.
Useabrushtoapplygreaseontothetelescopicextensionboom.
