JLG X20JPLUS - Starting the Electric Motor

USINGTHEMACHINE
91
MUX20JP021602
BoomLiftModels X20JPLUS
ThemachineswithDieselenginesareequippedwithanautomaticpreheatingsy‐
stem.Pushingbutton0(10)onremotecontrolwillbeactivatedapreheatof10se‐
conds.Iftheenginewillbestartedduringthistimethepreheatisstopped.See
paragraphconcerningthefunctionsoftheremotecontrolʺPushbuttons(p.
61)ʺ
beforeusingthisoption.
11.4.3.Startingtheelectricmotor
•Beforestartingthemotor,beclearlyawareofalltheproceduresdescribedin
theUSERANDOPERATIONMANUALandgetfamiliarwiththemeaningof the
safetystickers.
•Examine thesafetyrulesummary tablein themanualand  follow allthein‐
structionsgi
ventherein.
•Powerthemachinewithanelectriccablethroughtheconnectionpositioned
atthebottomneartheelectricmotor.Closetheswitchlocatedintheelectricalpa‐
nelnearthemotor.
Theenginemustbestartedwithallthecontrolbuttonsandjoysticks
in neutralposition. Alwaysmake sure there arenofor
eignobjects
(e.g.Branches)thatmayaccidentallyoperateacontrol, asthepla‐
tformmaymovesuddenlyoutoftheoperatorʹscontrolandcausese‐
riousharmto thingsand/orpeople.Makesurethatallthemanual
controlsfortheproportionalvalvesareatrest.
Fig.84 Powerlineconnection Fig.85 Ma
inelectricswitch
Beforeconnectingthemachinetothemainpowersupply:
