9.1.1. Display
Thedisplayisusedtoviewthestatusofthemachineandtheoperatinginforma‐
tionnecessaryorusefulfortheoperator.Whenthemachineʹsmaincontrolboard
ispoweredviatheenginekey,theinformationtobeshownonthedisplayissent
totheremotecontrol.Thisoper
ationhasavariableduration.Normallyafewse‐
condsaresufficient,howeverthefollowingscreenmayappearonthedisplay:
Inthiscaseab out10‐15minutesareneededtosendalltheinformationfromthe
mainboardtotheremotecontrol.Themachinecannotworkduringthisperiod.
Displaymainscreen
Whenthemachineisstarted,themainscreenisdisplayed,givingageneralover‐
viewofthemachinestatus .Forthesakeofsimplicityandclarityalayoutispro‐
videdwith8icondisplaypositions.
Fig.30 Downloadiconsremotecontrol
Donotstopthemachineoroperateitdu
ringthisperiod.
Fig.31 Mainscreenexample Fig.32 Locationdiagramicons
