BoomLiftModels X20JPLUS
INSTRUMENTSANDCONTROLS
MUX20JP021602
POSITION3:
Position3displaystheselectedengineandtheenginestatus.
AnXontheiconindicatesthattheengine/motorisoff,noXindicatesthatitison.
POSITION4:
Position4displaystheselectedspeedorthereducedspeedfortheLithium:
POSITION5:
Position5displaystheiconconfirmingthatoverhe
admovementsareenabled.
Thisiconmeansthatallconditionsforusingtheoverheadmovementshavebeen
checkedandtheaerialpartcanbe lifted.Noicononmeansthattheaerialpart
cannotbelifted.Inplaceofthisicon,thebasketoverloadiconmaybeshown.
Fig.33 Petrol/Dieselengine Fig.34 Elect
ricmotor
Fig.35 Slow Fig.36 Normal Fig.37 Fast
Fig.38 Reduced
Fig.39 Stabilizedmachine
