BoomLiftModels X20JPLUS
MAINTENANCE
MUX20JP021602
12.3.MAINTENANCECONTROLPOSITIONWITHREMOTECONTROL
FROMTHEGROUND
Asacontroldeviceformaintenance,youcanusetheremotecontrolinthebasket
(orasecondremotecontroloptional)connectingittotheappropriateseatonthe
machine.
Thistypeofoperationisonlyallowedincaseofmachinemaintenancebyquali‐
fi
edpersonnel.
Proceedasfollowstousethisfunction:
1 Ifyouhavenotalready,
orisnotinstalledonthe
machine ask the kit to
useremotecontrolfrom
theground at an autho‐
rizedservice.
Fig.152 Kituseremotecontrolfromtheground
2 With the unit off (igni‐
tion key to OFF), con‐
nect the cable of the ki
t
totheconnectorlocated
in the electrical box un‐
derthe guard.Nowcon‐
nect the remote to the
cableservice.Ifthekitis
already installed on the
machine connect direct‐
ly the  remote control to
thecableservice.
Fig.153 Positionconnectoroptionalsecondremote
