JLG X20JPLUS - Electrical Connection of Remote Control

USINGTHEMACHINE
131
MUX20JP021602
BoomLiftModels X20JPLUS
11.6.ELECTRICALCONNECTIONOFREMOTECONTROL
• Disconnectthecablefromtheremotecontrolusingthecorrespondingscrew
connection.
•Makesurethereisnomoistureintheremotecontrol connectorandclosethe
remotecontrolsealingplug.
•Make sure thereisnomoisture intheelectric cable connectorandclosethe
electriccablesealingplug.
•T
oreconnecttheremotecontrol,follow thesameprocessinthereverseorder.
Theelectricaldisconnection/connectionoftheremotecontrolMUSTbecar‐
riedoutexclusivelywiththemotorkeyinpositionOFFandwiththemains
powerdisconnected.
Fig.143 Remotecontrolconnection
