JLG X20JPLUS - Emergency Position Controls; Selection Panel, Emergency Stop and Starting

74
BoomLiftModels X20JPLUS
EMERGENCYDEVICE
MUX20JP021602
Thekeyusedtoactivatethesafetydevicebypassisleadsealedonthesideofthe
electricalcomponentscompartmentnearthebattery.Forcetheleadsealingtore‐
moveit.Afterusingthesafetydevicebypassanaftersalescentremustbecon‐
tacted in order to verify the causes that de
termined the need to use the safety
devicebypassandtoleadsealthekey.
10.5.EMERGENCYPOSITIONCONTROLS
10.5.1.Selectionpanel,emergencystopandstarting
Consideringthehazardderivingfromtheuseoftheplatformduring
thebypassofthesafetydevices,carefullyreadtheparagraphsregar‐
dingtheuseofthesafetydevicereleasekeyselect
orswitch.
Thesafetydevicebypasssystemisusedto movethemachinewitha
higherloadthanthelimitloadallowedinsidethebasket;theoverlo‐
adalarmisnonethelessdisplayedandthebeeperwarnstheoperator
ofthedangerousconditions.Thisdevicemustonlybeusedbyexpert
pers
onneltrainedonhowtousethemachine,whiletheenduser,who
does not fully know the machineʹs operating principles, is not al‐
lowedtousethisdevice.
Thesafetydeviceelectroniccontrolboard recordswhenthesafetydevicebypass
keyisusedandthemovementscarriedoutduringtheseoper
ations.
Fig.70 SelectorPetrol/Dieselversion Fig.71 SelectorLithiumversion
