JLG X20JPLUS - Emergency Operations on the Carriage: Moving the Platform Stabilisers Using the Hand Pump to Allow the Machine to be Transported

128
BoomLiftModels X20JPLUS
USINGTHEMACHINE
MUX20JP021602
11.5.6.Emergencyoperationsonthecarriage:movingtheplatformstabilisers
usingthehandpumptoallowthemachinetobetransported
Toraisethestabilisersfromthegroundinordertobeabletotransportthemachi‐
ne,proceedasfollows:
Thehydraulichandpumpcanbeusedtomovethestabilisersand se
tthema‐
chineinthetransportconfigurationonlyafterclosingcompletelytheaerialpart
oftheplatform.
1 Placetheemergency key
onthe electricalcompo‐
nents compartment, re‐
moving it from the
machineʹs key holder,
where it is sealed with
lead;
Fig.136 Batterycut‐out
2 Check that the machine
iscompletelyclosedand
aligned;
Fig.13
7 Machineclosedandaligned
