JLG X20JPLUS - Foot Switch (Optional)

64
BoomLiftModels X20JPLUS
INSTRUMENTSANDCONTROLS
MUX20JP021602
IfthestartbuttonsarepressedwithanemergencySTOPbuttonpressed,starting
willbeimpossible.ThisconditionisindicatedbytheiconSTOPinposition7ʺDi‐
splay(p. 55)ʺ. If theoperator attempts tostartoneof the two motorswhilethe
other is a lready running,starting will be impossible and the icon showing the
motora
lreadyonwillappearatthecentreofthescreen.
9.2. FOOTSWITCH(OPTIONAL)
Insideofthebasketisfittedafootswitchdevicethatmustbepushedtoallowthe
movementofthe machinefrom thebasket.Ifyoutrytomove themachinewi‐
thoutthefootswi
tchpushedthemovementwillbeprohibitedandamessageon
thedisplaywillappearinformingthatitisnecessarypushthepedaltowork.If
youhavenotmademovesto7secondsafterpressingthepedalthismustberele‐
aseandpressedagaintoresumework.
Allowstheelectricmotortobeswi
tchedon/off.Ifthebuttonispres‐
sedwiththeengineon,thiswillbestopped.
Buttons5and6whenpressedsimultaneouslyalsoactivatethehorn(optional).
Fig.54 Footswitch Fig.55 Iconpushfootswitch
