JLG X20JPLUS - Overall Dimensions of the Machine

18
BoomLiftModels X20JPLUS
TECHNICALINFORMATIONS
MUX20JP021602
7.3. OVERALLDIMENSIONSOFTHEMACHINE
Maximumlengthintravelconfig urationwithbasketin‐
stalled
5011mm
Trackwidthclosed/open 795/1095mm
Maximumheightintravelconfigurationwithfootplates
removed
1998mm
Maximumattachmentangle 20°/21°
Maximumstabilisationangle 15°
Maxstabiliserbaseside(disccentre) 2922x2925mm
Fig.5 Standardversionwith2personbasket
