Thesensorinsidethecylinderisnotworkingproperly.
POSITION8:
Position8displaysthebatterychargestatusortheiconindicatingthebatteryis
beingrechargedintheLithiumversion.
Position8isusedtoshowtheselectionoftheemergencydescentoperationfrom
thebasketwithsolenoidvalvesonthecylinders.
9.
1.2. Joystick
Usingthe joysticks the operator selects the movement to be performed, thedi‐
rectionandthespeed.Thedirectionofthejoystickdeterminesthedirectionofthe
movement.The degreeofmovementofthejoystickdeterminesthespeed. The
morethejoystick ismovedawayfromthecentralneutralposition,thefas
terthe
movementsobtained.
Startingfromtheleftinthefigureshownbelow,thejoysticksarenumberedfrom
1to9.Thefollowingtableshowsthemovementcontrolledanditsdirectionde‐
pendingonthejoystickshiftingdirection.
A=Forward
B=Backward
Fig.48 Readingerrorsensorcylinder1 Fig.49 Readingerrorsensorcylinder3
Fig.50 Lit
hiumbatterystatus Fig.51 Lithiumbatterycharging
Fig.52 Gravityemergencydescend
Inadditiontothemainscreendescribedabove,thereareotherfunctionaldisplays
thatwillbedescribedsuccessively.
