Thehandpumpisusedtopressuriseoilforemergencymovementsmadeneces‐
sarybyanybreakdownofthemainhydraulicsystem.Thehandpumphasama‐
nualswitchusedtoselectwhetherpartofmachinetocontroldependingonthe
selectionmadeaccordingtothelogicdescribedinthele
gendabove.
Fig.66 Handpump Fig.67 Handpumphy‐
draulicdiverter
Fig.68 Handpumpdecals
instructions
Thehandpumpisprovidedwithare‐
movable handle which is fixed on the
carriageofthemachine.
