USINGTHEMACHINE
97
MUX20JP021602
BoomLiftModels X20JPLUS
EnablingoftheJIBisindicatedbytheiconinposition5ontheremotecontrol.
The JIB arm can be raised during travel only  from the control position on the
ground.
BeforeraisingtheJIBboomfortravel,checkthefollowingconditions:
•Allthestabilisersmustbeliftedfromthegro
und;
•Nooperatorsmustbeinthebasket;
•Thecontrolpositiononthegroundmustbeused(theremotecontrolmustnot
beinplaceinthebasket);
•Theaerialpartsafetydevicebypasskeymustnothavebeenactiva tedafterthe
machinehasbeenclosedandaligned.
Ifoneormoreofthesecond
itionsisnotsatisfied,theJIBboomcannotbeusedand
oneofthefollowingerrorscreenswillbeshown.
Performthisoperationonlywhenreallynecessary.Inallothersitua‐
tions,travelwiththemachineclosedandaligned.
Fig.88 Consent touseJIBduringtravelli ng
Fig.89 Errormachinenotstabilized
