BoomLiftModels X20JPLUS
SAFETYDEVICE
MUX20JP021602
Whenbothropesareintegral,thebalancingsystemisparalleltothemachineaxle
andthemicroswitchmustbereleased.Ifthemicroswitchisnotreleaseddueto
ananomalyononeofthetworopes,awarningmessageappearsontheremote
controldisplay.
Fig.18 Ropesmicroswitch Fig.19 Microswitchposi‐
tion
Fig.20 Rope
serror
