184
BoomLiftModels X20JPLUS
SAFETYSTANDARDSFORTRANSPORT
MUX20JP021602
•withdrawthebasketfromabove;
Reassemblethebasketasfollows:
•fit thebasketintothefixingpinsonthe basketsupport,makingsure that it
movesdownwardsasparalleltothebasketsupportaspossible.
•Tightenthetwoaluminiumcovers.
Fig.176 Caplockpin
