78
BoomLiftModels X20JPLUS
EMERGENCYDEVICE
MUX20JP021602
2 Basketrotationcontrol Movingleverdownwards:
basketrotatesclockwise
Movingleverupwards:
basketrotatesanticlockwise
3 JIBcontrol Movingleverupwards:
ilJIBopens
Movingleverdownwards:
ilJIBcloses
4 Extensionarmcontrol Movingleverupwards:
extensionarmout
Movingleverdownwards:
extensionarmin
5 Thirdarmcontrol Movingleverupwards:
3°armup
Movingleverdownwards:
3°armdown
6 First‐Secondarmcon‐
trol
Movi
ngleverupwards:
1‐2°armup
Movingleverdownwards:
1‐2°armdown
7 Rotationcontrol Movingleverupwards:
clockwiserotation
Movingleverdownwards:
anticlockwiserotation
Ref. Description Drive/Motion
