6.5.2 Положения измерения при различных
режимах Alu
Выбор режима Alu измерительной ручкой
должен производиться только в ручном режиме.
Рис. 6-12
(1)
(2)
.
* :
F4 ALU P.
Рис. 6-12
• = (1)
= (2)
normal .
Easy Alu.
Alu 1
.
Easy Alu.
F2.
Alu 2 ,
(NOMINAL). Easy
Alu.
F2.
Alu 2P - ,
Alu 3 ,
.
Easyalu.
(NOMINAL).
F2.
Alu 3P ,
;
.
Alu 4 , -
.
Alu 5 ,
- .
6.5.2 Reading positions for various Alu
types
The Gauge should be used to select the various Alu
only in MANUAL Mode
Fig. 6-12 shows the corrected reading positions of the
measurement gauge on different types of rim (1), depending
on the required weight application positions (2); adhesive
and clip-on weights.
* Select the menu key:
F4 to recall the required ALU P weight positions.
Fig. 6-12
• = Point of application of gauge arm (1)
= Given weight position (2)
normal Normal weight positioning. Clip-on weight positions
on the rim flange - this mode is presented
immediately by the Easyalu function.
Alu 1 Adhesive weights applied symmetrically to the rim
flanges with NOMINAL weight positioning. Function
not included in Easyalu mode. After reading, set
mode from Menu F2.
Alu 2 Adhesive weights - Adhesive weight on rim flange,
adhesive weight hidden in rim disc with NOMINAL
positioning.Function not included in Easyalu mode.
After reading, use internal calibration to set mode
from Menu F2
Alu 2P Adhesive weights - Adhesive weight on rim flange,
adhesive weight hidden in rim disc; the
compensation planes for the adhesive weights are
read precisely using internal calibration
Alu 3 Clip-on weight on left rim flange, adhesive weight
hidden in rim disc. Function not included in Easyalu
mode. Weight positioning is NOMINAL. After
reading, set mode from Menu F2.
Alu 3P Clip-on weight on left rim flange, adhesive weight
hidden in rim disc; the compensation planes for
the adhesive weight is read precisely using internal
calibration.
Alu 4 Balance clip fitted on left rim flange, adhesive weight
attached to right bead seat..
Alu 5 Balance clip fitted on right rim flange,
adhesive weight attached to left bead seat
