− 148 −
3
4
5
6
3) Input the number of times of thread trimming.
Next, input the number of times of thread trimming
per process. When number of times of thread
trimming button 5 in the previous page is
pressed, the number of times of thread trimming
input screen is displayed.
Input the value you desire with ten keys or UP/
DOWN buttons.
After the input, press ENTER button 3.
When the input value is 0, count of the
number of times of thread trimming
is not performed. Use this function by
connecting the external switch.
4) Start the measurement.
When START button 4 is pressed,
measurement of each data is started.
5) Stop the count.
Display the working measurement screen referring
to 1) and 2) of "17-6 Observing the working
measurement information".
STOP switch 5 is displayed when the
measurement is being performed. When STOP
switch 5 is pressed, the measurement is
stopped.
After the stop, START button 4 is displayed
at the position of STOP button. To continue
measuring, press START button 4 again.
The measured value is not cleared until CLEAR
button 6 is pressed.
To Next Page
