JUKI DP2100 - 21 Using Check Program; Displaying the Check Program Screen

− 155 −
2
1
Press 1 key for three seconds, and CHECK
PROGRAM button 2 is displayed on the
screen. When this button is pressed down, the check
program screen is displayed.
There are 5 items below in the check program.
Auxiliary pedal setting
Refer to "21-2 Performing the auxiliary pedal
setting".
Checking of A/D value of auxiliary pedal
Refer to "21-3" Performing checking of A/D value
of auxiliary pedal".
LCD check
Refer to "21-4 Performing LCD check".
Touch panel compensation
Refer to "21-5 Performing touch panel
compensation".
Input signal check
Refer to "21-6 Performing the input signal".
Output signal check
Refer to "21-7 Performing the output signal".
21. USING CHECK PROGRAM
21-1 Displaying the check program screen
