Cable Specifications for Console and Management Connections for an ACX5000
Router
Table 47 on page 93 lists the specifications for the cables that connect the ACX5000
routers to a management device.
NOTE: The ACX5000routerscanbeconfiguredwithSFP managementports
that support 1000BASE-SX transceivers. See “Interface Specifications for
SFP, SFP+, and QSFP+ Transceivers for an ACX5000 Router” on page 62 for
more on the fiber-optic cables required for use with these transceivers.
Table 47: Cable Specifications for Console and Management Connections for the ACX5000
Router
Device
ReceptacleMaximum LengthCable SuppliedCable Specification
Port on ACX5000
Routers
RJ-457 feet (2.13 meters)One 7-foot (2.13-meter) long
RJ-45 patch cable and RJ-45 to
DB-9 adapter
RS-232(EIA-232) serial cableConsole port
RJ-45328 feet
(100 meters)
One 7-foot (2.13-meter) long
RJ-45 patch cable
Category 5 cable or
equivalent suitable for
1000BASE-T operation
Management port
Grounding Cable and Lug Specifications for an ACX5000 Router
For installations that require a separate grounding conductor to the chassis, the router
must be adequately grounded before power is connected to ensure proper operation
and to meet safety and electromagnetic interference (EMI) requirements. To ground a
ACX5000 router, connect a grounding cable to earth ground and then attach it to the
chassis grounding points.
WARNING: The router is pluggable type A equipment installed in a
restricted-access location. It has a separate protective earthing terminal
provided on the chassis in addition to the grounding pin of the power supply
cord. This separate protective earthing terminal must be permanently
connected to earth ground for installations that require a separate grounding
conductor to the chassis.
93Copyright © 2015, Juniper Networks, Inc.
