CAUTION: Do not bend fiber-optic cables beyond their minimum bend
radius.Bending the cablesbeyondtheir minimumbend radius can damage
the cables and cause problems that are difficult to diagnose.
3. Remove the cable connected to the transceiver (see “Disconnecting a Fiber-Optic
Cable from an ACX5000 Router” on page 145). Cover the transceiver and the end of
each fiber-optic cable connector with a rubber safety cap immediately after
disconnecting the fiber-optic cables.
4. Using your fingers, pull the ejector lever away from the transceiver to unlock the
transceiver.
CAUTION: Before removingthe transceiver, make sure you open theejector
lever completely until you hear it click. This prevents damage to the
transceiver.
5. Grasp the transceiver ejector lever and gently slide the transceiver approximately
0.5 in. (1.3 cm) straight out of the port.
CAUTION: To avoid electrostatic discharge (ESD) damage to the
transceiver, do not touch the connector pins at the end of the transceiver.
6. Using your fingers, grasp the body of the transceiver and pull it straight out of the port.
7. Place the transceiver in the antistatic bag or on the antistatic mat placed on a flat,
stable surface.
8. Place the dust cover over the empty port.
Related
Documentation
Installing a Transceiver in an ACX5000 Router on page 142•
Installing a Transceiver in an ACX5000 Router
The transceivers for the ACX routers are hot-removable and hot-insertable
field-replaceable units (FRUs). You can remove and replace them without powering off
the device or disrupting device functions.
Before you begin installing a transceiver in an ACX router, ensure that you have taken the
necessary precautions for safe handling of lasers (see “Laser and LED Safety Guidelines
and Warnings for the ACX Router” on page 178).
Ensure that you have a rubber safety cap available to cover the transceiver.
Copyright © 2015, Juniper Networks, Inc.142
ACX5048 and ACX5096 Universal Access Router
