(QSFP+) ports. Each SFP+ port can operate as a native 10-Gigabit Ethernet port or as a
1-Gigabit Ethernet port when 1-gigabit optics are inserted. Each QSFP+ port (48 through
53) can operate as a 40-Gigabit Ethernet port or be channelized to operate as four
independent 10-Gigabit Ethernet ports (a total of 24 10-Gigabit Ethernet ports). The
6 QSFP+ ports can be used as either access ports or uplink ports. The ACX5048 provides
full duplex throughput of 1.44 Tbps. The ACX5048 has a 1 U form factor and is shipped
with redundant fans and redundant power supplies. The router can be ordered with
front-to-back airflow (air out or AFO) and with AC or DC power supplies.
Figure 1: ACX5048 Port Panel
ACX5048 can be used only as a standalone router.
ACX5096 Router
As shown in Figure 2 on page 4, the ACX5096 is a is a 10-Gigabit Ethernet enhanced
small form-factor pluggable (SFP+) top-of-rack router with 96 SFP+ ports and 8 quad
SFP+ (QSFP+) ports. Each SFP+ port can operate as a native10-Gbps port or as a 1-Gbps
port. The QSFP+ ports 96 and 100 can operate at native 40 Gbps speed or can be
channelized to 4 independent 10 Gbps port speeds. The 8 QSFP+ ports can be used as
either access ports or as uplinks. The ACX5096 has a 2 U form factor and is shipped with
redundant fans and redundant power supplies. The router can be ordered with
front-to-back airflow (air out or AFO) and with AC or DC power supplies.
Figure 2: ACX5096 Port Panel
ACX5096 can be used only as a standalone router.
Related
Documentation
ACX5000 Router Models on page 5•
• ACX5000 System Software Overview on page 10
• Protocols and Applications Supported by the ACX Routers on page 10
