Xcvr 0 REV 01 740-011613 PD63CUT SFP-SX
Xcvr 9 REV 01 740-021308 ARS17R5 SFP+-10G-SR
Xcvr 12 REV 01 740-011782 P92080R SFP-SX
Xcvr 14 REV 01 740-031851 AM1229SY9ZX SFP-SX
Xcvr 20 REV 01 740-031851 PN340SM SFP-SX
Xcvr 24 REV 02 740-011613 PJ215BU SFP-SX
Xcvr 29 REV 01 740-013111 7161618 SFP-T
Xcvr 32 REV 01 740-021308 ARS1778 SFP+-10G-SR
Xcvr 34 REV 01 740-021308 ARR3RM2 SFP+-10G-SR
Xcvr 37 REV 01 740-021308 ARS1769 SFP+-10G-SR
Xcvr 39 REV 01 740-021308 ARR3WHU SFP+-10G-SR
Xcvr 40 REV 02 740-011613 PJ216BK SFP-SX
Xcvr 41 REV 01 740-031851 PM734F3 SFP-SX
Xcvr 46 REV 01 740-021308 ARR41L8 SFP+-10G-SR
Xcvr 47 REV 02 740-011613 AM0943SEMZ5 SFP-SX
Xcvr 48 REV 01 740-032986 QD417082 QSFP+-40G-SR4
Xcvr 49 REV 01 740-032986 QD416522 QSFP+-40G-SR4
Xcvr 52 REV 01 740-032986 QE120433 QSFP+-40G-SR4
Power Supply 0 REV 03 740-043886 1GA44090680 JPSU-650W-DC-AFO
Power Supply 1 REV 03 740-043886 1GA44090685 JPSU-650W-DC-AFO
Fan Tray 0 ACX5K Fan Tray 0, Front
to Back Airflow - AFO
Fan Tray 1 ACX5K Fan Tray 1, Front
to Back Airflow - AFO
Fan Tray 2 ACX5K Fan Tray 2, Front
to Back Airflow - AFO
Fan Tray 3 ACX5K Fan Tray 3, Front
to Back Airflow - AFO
Fan Tray 4 ACX5K Fan Tray 4, Front
to Back Airflow - AFO
NOTE: You must remove the fan module to read the fan serial number from
the serial number ID label. The fan module serial number cannot be viewed
through the CLI. Fan Tray 2 refers to the third module from the left, counting
from 0.
Locating the Chassis Serial Number ID Label on an ACX5000 Router
The location for the chassis serial number ID label is product SKU-dependent. On the
ACX5000 router product SKUs, the serial number ID label is located on the left side of
the port panel. See Figure 55 on page 155 and Figure 56 on page 155 for examples of where
to find the serial number ID.
