Table 8: Chassis Status LEDs on an ACX5000 Router
DescriptionStateColorName
The router is halted or there is no alarm.OffUnlitALM–Alarm or beacon
A major hardware fault has occurred, such
as a temperature alarm or power failure,
and the router has halted. Power off the
ACX5000 router by setting the AC power
source outlet to the OFF (O) position, or
unplugging the AC power cords. Correct
any voltage or site temperature issues,
and allow the router to cool down. Power
on the ACX5000 router and monitor the
power supply and fan LEDs to help
determine where the error is occurring.
On steadilyRed
A minor alarm has occurred, such as a
software error. Power off the ACX5000
router by setting the AC power source
outlet to the OFF (O) position, or
unplugging the AC power cords. Power on
the ACX5000 router and monitor the
status LEDs to ensure that Junos OS boots
properly.
On steadilyAmber
The router is powered off or halted.OffUnlitSYS–System
Junos OS for ACX Series is loaded on the
router.
On steadilyGreen
The router is a linecard member.OffUnlitMST–Master
The router is a standalone router.On steadilyGreen
The beacon feature is not enabled on the
router. This feature is enabled using the
request chassis beacon command.
OffUnlitID–Identification
The beacon feature is enabled on the
router. This feature is enabled using the
request chassis beacon command.
BlinkingBlue
