DCE80-100E
Technical Handbook
Specifications
2
P.Group 40
TDCE01
04GB
Torque converter and gearbox
Model Clark - 13.7 HR 32000
Number of gears 3F – 3R
Oil capacity, total system, l 32
Oil grade See group 90
Oil operating temperature, °C 82–93
Max. permissible temperature, °C 120
Clutch pressure, bar
with parking brake applied,
oil temp. 82–93°C,
engine idling at 625 r/min
17–20
All clutch pressures should be
equal to within 0.4 bar as indicat-
ed on pressure gauge in cab.
Clutch type Multiple disc, hydraulic.
Automatic wear compensation
(no adjustment). All clutches oil
cooled and lubricated.
Stall speed, r/min 1990±50
Oil filtration Full-flow oil filter with safety by-
pass; also strainer screen in
sump at bottom of transmission
case.
Drive axle
Model Kessler D81
Brake system Wet disc brakes
Parking brake system Spring-activated disc brake on
drive axle input-shaft.
Wheel dimensions, in
/ Tyre pressure, MPa
DCE70: 12.00x24 - 1.0
DCE90: 14.00x24 - 1.0
Oil capacity, liter B=4000
B=4500
3.5 each hub, 51 differential
2,0 each hub. 63 differential
Oil grade See Group 90
Tightening torque
Drive axle mounting bolts
(oiled), Nm (kpm
Rim clamp nuts, Nm (kpm)
M24: 650 (66 (M30: 1275 (130)
M22: 650 (66)
Universal drive axle joint,
Nm (kpm)
UNF 3/8'': 59 (6.0)
