DCE80-100E
Technical Handbook
Periodic supervision
11
P.Group 90
TDCE01
04GB
Every 500 hours
Item Unit Action Remarks
1 Truck Wash Note! Do not use high-pressure
on bearings or bearing housings
2 Radiator Clean the fins of the radiator with
water and detergent
Note! Do not use high-pressure.
3 Engine Check the oil and coolant con-
nections for leakage
4 Air cleaner Change the filter element if the
indicator shows red.
See Group 30
5 Battery cables, terminals and
fuses
Clean the terminals and apply
petroleum jelly. If necessary, re-
place cables and terminals.
6 Turbo charger Check for leakage. See Group 30
7 Exhaust system Check for leakage.
8 V-belts Check the belt tension See Group 30
9 Brakes Check for oil leakage.
Test brake performance.
Functional test WDB incl parking
brake.
See Group 70
10 Steering axle Check for play and damage
11 Steered and driven wheels Check the wheel alingment.
Check for damage to rims and
tyres.
Tighten the wheel nuts
See Group 40 resp
60 Specifications
12 Drive axle and propeller shaft Check oil level
Tighten bolt joints
Check for leakage
See Group 40 Specifications
13 Transmission Check for oil leakage.
14 Mast and carriage Check for hose damage.
Check hose stretching
Check sliding plates and support
wheels.
Check tilt cylinders for cracks
Check bolted joints
See Group 80
15 Chains Wash, check and adjust length.
Lubricate
See group 80
16 Sidelift Check that all sensors are un-
damaged and free from grease.
Check for damage.
Check function, see group 80
17 (Air conditioner) Check the performance See Group 10
18 Lubrication points, oil and filter
changes in accordance with the
Lubrication chart.
19 Measures according to
Daily supervision
