DCE80-100E
Technical Handbook
Mast and carriage
Description
3
P.Group 80
TDCE01
04GB
Lift mast
The mast on a Kalmar truck is of very sturdy design. The number
of welds has been kept down to a minimum, to ensure the highest
possible strength. The stresses on the mast components are low.
The mast sections are made of high-strength steel and have
slender dimensions, to restrict the field of vision as little as possi-
ble.
All support wheels for longitudinal forces are fitted with high qua-
lity roller bearings. The traditional side support rollers are repla-
ced by plastic sliding plates, there are 4 plates between inner and
outer mast. Between carriage and inner mast there are 4 plates
and 8 plates between carriage and sidelift attachment.
KL1125a
