Kalmar DCE80-100E - Carriage Description

DCE80-100E
Technical Handbook
Mast and carriage
Description
4
P.Group 80
TDCE01
04GB
Carriage
Two different integrated carriages are available - a fixed carriage
for attachments with twist-locks and a carriage with hydraulic lev-
elling ±4° for attachments with hooks. Both carriages have sup-
port wheels to bear longitudinal stresses and sliding plates for
lateral stresses.
KL1400
KL1401
Carriage without levelling
Carriage with hydraulic levelling
