DCE80-100E
Technical Handbook
Brake system
Description
23
P.Group 70
TDCE01
04GB
49
31
33
36a
36b
31. Tank
33. Service brake cylinder
36a. Brake cooling curcuit supply
36b. Brake cooling curcuit, return
49. Oil cooler
A. From brake pedal
Brake system, cooling circuit supply
A
