DCE80-100E
Technical Handbook
General
7
P.Group 00
TDCE01
04GB
1
2
3 5
4
6
7
1. Lifting mast, free lift mast with double cylinders
2. Operator’s cab, rubber suspended
3. Engine, six cylinder diesel with turbocompressor
4. Steering axle with pendular suspension and
double-acting steering cylinder
5. Gearbox, combined with torque converter
6. Drive axle, with hub reduction and oil sooled, hydraulic
brake system
7. Carriage with side lift attachment
Hydraulically controlled length adjustment and side-shift
