ULTRAFLOW®54(H)/(J)
KamstrupA/S∙TechnicalDescription∙5512‐1554_J1_GB_04.2018
55
Connection Distance piece Gland
G¾ (R½) DN15 ø15 ø14
G1 (R¾) DN20 ø20 ø19.5
G5/4 (R1) DN25 ø25 ø25.5
G1½ (R5/4) DN32 ø32 ø32
G2 (R1½) DN40 ø40 ø39
Table 21. Distance pieces.
Installation (electrical conditions):
To avoid external disturbances and to achieve an electrical interface as that of MULTICAL
®
, we recommend to use
a Pulse Tester (see paragraph 9.5) or to connect a Pulse Transmitter between ULTRAFLOW
®
and the respective test
equipment, which is counting pules, in order to achieve galvanic separation. If the test equipment supports NOWA,
see paragraph 9.6 for further information.
