13-8 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 13: Test Script Builder (TSB) Series 2600A System SourceMeter® Instruments Reference Manual
The toolbar at the top of the Test Script Builder is used to save the displayed script file. As
explained in
Figure 13-5, the script file can be saved in the same folder and/or saved in a different
folder.
Figure 13-5
Saving a script in Test Script Builder
Creating new script files
A script project can be made up of one or more script files. Figure 13-6 shows how to add a script
file to a project folder.
Click File and then click Save in the the drop-down menu.
OR
To save the displayed script file in the same project folder:
Click the diskette icon.
To save the displayed script file in a different project folder:
A) Click File and then click Save As in the the drop-down menu to
display the Save As window.
B) In the Save As window:
1. Select (click) the project folder for the script file.
2. If desired, change the name of the script File name. The .esp
extension must be included in the file name.
