19-82 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 19: Remote Commands Series 2600A System SourceMeter® Instruments Reference Manual
lan.trigger[N].ipaddress
Replace N with values 1-8.
Attribute Sets the IP address for outgoing trigger events.
Default “0.0.0.0”
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage ipaddress = lan.trigger[lanevent].ipaddress
lan.trigger[lanevent].ipaddress = ipaddress
ipaddress Sets and stores the LAN address for this attribute.
lanevent The LAN event number.
Remarks • ipaddress must be a string in dotted decimal notation.
• After changing this setting, lan.trigger[n].connect must be called before outgoing
messages can be sent.
lan.trigger[N].mode
Replace N with values 1-8.
Attribute Sets the trigger event operation/detection mode.
Default lan.TRIG_EITHER
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage mode = lan.trigger[lanevent].mode
lan.trigger[lanevent].mode = mode
lanevent The LAN event number.
mode The trigger mode.
Choose one the following values for mode:
lan.TRIG_EITHER Input. Detects rising or falling edge trigger packets
Output. A negative state LAN trigger packet.
lan.TRIG_FALLING Input. Detects falling edge trigger packets.
Output. A negative state LAN trigger packet.
lan.TRIG_RISING Input. Detects rising edge trigger packets.
Output. A positive state LAN trigger packet.
lan.TRIG_RISINGA Input. Detects rising edge trigger packets.
Output. A positive state LAN trigger packet. Same
as lan.TRIG_RISING.
lan.TRIG_RISINGM Input. Detects rising edge trigger packets.
Output. A positive state LAN trigger packet. Same
as lan.TRIG_RISING.
lan.TRIG_SYNCHRONOUS Input. Detects falling edge trigger packets.
Output. A positive state LAN trigger packet.
lan.TRIG_SYNCHRONOUSA Input. Detects falling edge trigger packets.
Output. A positive state LAN trigger packet.
lan.TRIG_SYNCHRONOUSM Input. Detects rising edge trigger packets.
Output. A negative state LAN trigger packet.
Remarks • lan.TRIG_EITHER is the default mode.
• The lan.TRIG_SYNCHRONOUS values are provided for compatibility with digio and tsplink
triggering.
