2600AS-901-01 Rev. B / September 2008 Return to Section Topics 19-83
Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
lan.trigger[N].overrun
Replace N with values 1-8.
Attribute Event detector overrun status.
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage overrun = lan.trigger[lanevent].overrun
lanevent The LAN event number.
overrun Indicates whether the trigger event detector is in the
overrun state.
Remarks • Read-only attribute indicating whether an event has been ignored because the event detector
was already in the detected state when the event occurred.
• Indicates the state of the LAN event receiver’s built-in event detector.
• It does not indicate whether an overrun has occurred in any other part of the trigger model that is
monitoring the event.
• It is not an indication of an output trigger overrun. Output trigger overrun indicators are provided
in the status model.
lan.trigger[N].protocol
Replace N with values 1-8.
Attribute Sets the LAN protocol to use for sending trigger messages.
Default lan.TCP
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage protocol = lan.trigger[lanevent].protocol -- Reads LAN protocol.
lan.trigger[lanevent].protocol = protocol -- Writes LAN protocol.
lanevent The LAN event number.
protocol Sets the protocol used by the trigger.
Remarks • The LAN trigger will listen for trigger messages using either protocol but will use the selected
protocol for outgoing messages.
• After changing this setting, lan.trigger[n].connect must be called before outgoing event
messages can be sent.
• protocol must be either lan.TCP, lan.UDP, or lan.MULTICAST. The default is lan.TCP.
• When lan.MULTICAST is selected, the ipaddress attribute will be ignored and event
messages will be sent to multicast address 224.0.23.159.
lan.trigger[N].pseudostate
Replace N with values 1-8.
Attribute Tracks the simulated line state for the LAN trigger.
Default 1
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage pseudostate = lan.trigger[lanevent].pseudostate
lan.trigger[lanevent].pseudostate = pseudostate
lanevent The LAN event number.
pseudostate The simulated line state.
Remarks • lan.trigger[n].pseudostate can be set to initialize the pseudo state to a known value.
• Setting this attribute will not cause the LAN trigger to generate any events or output packets.
