3 Features and Functions
146 Keysight 33210A User’s Guide
– Front panel operation: Press and press the I/O softkey. Select LAN, then
Modify Settings, followed by IP Setup. By default, Auto IP is On. Press the
Auto IP On/Off softkey to toggle its state.
– Remote interface operation:
SYSTem:COMMunicate:LAN:AUTOip[:STATe] {OFF|0|ON|1}
SYSTem:COMMunicate:LAN:AUTOip[:STATe]?
IP Address (LAN)
You can enter a static IP address for the 33210A as a four-byte integer expressed
in dot notation (“nnn.nnn.nnn.nnn”, where “nnn” in each case is a byte value from
0 to 255). Each byte is expressed as a decimal value, with no leading zeros (for
example, 169.254.2.20).
– You need not enter an IP address if DHCP or Auto IP is in use. However, If both
DHCP and Auto IP fail to assign a valid IP address, the currently configured
static IP Address is used.
– Contact your network administrator for a valid IP address to use for your
function generator.
– Enter the IP address using the numeric keypad (not the knob).
– The IP address is stored in non-volatile memory and does not change when
power has been off or after a remote interface reset.
– Front panel operation: Press and press the I/O softkey. Select LAN, then
Modify Settings, followed by IP Setup. By default, DHCP and Auto IP are On.
Select DHCP Off and Auto IP Off. The IP Address field appears. Enter the
desired address (for example: 169.254.11.22).
– Remote interface operation:
SYSTem:COMMunicate:LAN:IPADdress <address>
SYSTem:COMMunicate:LAN:IPADdress?
If you want to set an IP address, Subnet Mask, or Default Gateway manually, you
must turn off both DHCP and Auto IP. Then change the IP setup as described in
the following sections.
