Features and Functions 3
Keysight 33210A User’s Guide 75
Output Units
Applies to output amplitude only. At power-on, the units for output amplitude are
volts peak-to-peak.
– Output units: Vpp, Vrms, or dBm. The default is Vpp.
– The unit setting is stored in volatile memory. The units are set to “Vpp” when
power has been off or after a remote interface reset (provided the Power On
state is set to “default”).
– The function generator uses the current units selection for both front panel and
remote interface operations. For example, if you select “VRMS” from the
remote interface, the units are displayed as “VRMS” on the front panel.
– The output units for amplitude cannot be set to dBm if the output termination
is currently set to “high impedance”. The units are automatically converted to
Vpp.
– Front-Panel Operation: Use the numeric keypad to enter the desired
magnitude and then press the appropriate softkey to select the units. You can
also convert from one unit to another from the front panel. For example, to
convert 2 Vpp to its equivalent value in Vrms, press and then press the
V
RMS
softkey. The converted value is 707.1 mVrms for a sine wave.
– Remote Interface Operation:
VOLTage:UNIT {VPP|VRMS|DBM}
