Error Messages 5
Keysight 33210A User’s Guide 309
-221
Settings conflict;
offset changed due to amplitude
The relationship between offset voltage and
output amplitude is shown below.
Vmax is the maximum peak voltage for the selected output termination (5 volts for
a 50Ω load or 10 volts for a high-impedance load). If the existing offset voltage is
not valid, the function generator will automatically adjust it to the maximum
dc voltage allowed with the amplitude specified.
| Voffset | <
Vmax –
-221
Settings conflict;
amplitude changed due to offset
The relationship between output amplitude
and offset voltage is shown below.
Vmax is the maximum peak voltage for the selected output termination (5 volts for
a 50Ω load or 10 volts for a high-impedance load).
If the existing amplitude is not valid, the function generator will automatically
adjust it to the maximum value allowed with the offset voltage specified.
Vpp <
2 × (Vmax – | Voffset |)
-221
Settings conflict;
low level changed due to high level
You can set the levels to a positive or negative value, but note that the high level
must always be greater than the low level. If you specify a high level that is less
than the existing low level, the function generator will automatically set the low
level to be 1 mV less than the high level.
