1 Quick Start
40 Keysight 33210A User’s Guide
To rack mount a single instrument, order adapter kit 5063-9240.
To rack mount two instruments side-by-side, order lock-link kit 5061- 8769 and
flange kit 5063-9212. Be sure to use the support rails in the rack cabinet.
In order to prevent overheating, do not block the flow of air into or out of the
instrument. Be sure to allow enough clearance at the rear, sides, and bottom of
the instrument to permit adequate internal air flow.
