2 Front-Panel Menu Operation
56 Keysight 33210A User’s Guide
4 Set the burst period.
Press the Burst Period softkey and then set the period to 20 ms using the
numeric keypad or the knob and cursor keys. The burst period sets the time
from the start of one burst to the start of the next burst (note the display icon).
At this point, the function generator outputs a continuous three-cycle burst (if
the output is enabled).
5View the waveform.
Press t
o view the waveform parameters.
To turn off the Graph Mode, press again.
You can generate a single burst (with the specified count) by pressing the
key. For more information, see “To Trigger a Sweep or Burst” on page 57.
You can also use an external gate signal to either turn the burst signal “on” or
“off” based on the external signal applied to the rear-panel Trig In connector. For
more information see “Burst Mode” on page 112.
