3.2.5 Output Units
Introduction
Applies to output amplitude only. At power-on, the units for output
amplitude are volts peak-to-peak.
Output Units
Vpp, Vrms, or dBm. The default is Vpp.
The unit setting is stored in volatile memory. The units are set to
“Vpp”when power has been off or after a remote interface reset (provided
the Power On state is set to “default”).
Characteristics
The 81150A / 81160A uses the current units selection for both front panel
and remote interface operations. For example, if you select “VRMS” from
the remote interface, the units are displayed as “VRMS” on the front panel.
Front-Panel
Operation
Use the numeric keypad to enter the desired magnitude and then press the
appropriate softkey to select the units. You can also convert from one unit to
another from the front panel.
Press the Ampl Softkey. Then select the desired unit as described in section
2.13.1.
Remote Interface
Operation
The following function is used to configure the output amplitude remotely:
:VOLTage[1|2] {VPP|VRMS|DBM}
