Introduction
81150A and 81160A User’s Guide 13
1 Introduction
Keysight
Technologies’
81150A / 81160A
Pulse Function
Arbitrary Noise
Generator
The Keysight Technologies 81150A and 81160A is a Pulse Pattern and
Function Arbitrary Noise Generator with built-in arbitrary waveform and
pulse capabilities
Its combination of bench-top and system features makes this Pulse Function
Arbitrary Noise Generator a versatile solution for your testing requirements
now and in the future.
Features and
Benefits
 81150A: 1 Hz-120 MHz pulse generation with variable rise/fall time
 81150A: 1 Hz-240 MHz sine waveform outputs
 81160A: 1 Hz-330 MHz pulse generation with variable rise/fall time
 81160A: 1 Hz-500 MHz sine waveform outputs
 Pulse, sine, square, ramp, noise and arbitrary waveforms
 FM, AM, PM, FSK, PWM modulation capability
 One or two channels
 81150A: 14-bit, 2GSa/s, 512 KSa deep arbitrary waveform memory
per channel
 81160A: 14-bit, 2.5GSa/s, up to 256 KSa deep arbitrary waveform
memory per channel
 USB, GPIB and LAN connectivity.
 Glitch free change of timing parameters delay, frequency, transition
time, width, duty cycle
 LXI class C compliant
Benchtop Testing
The 81150A / 81160A features a graphic display showing all pulse
parameters at a glance. The cursor keys and the modify knob allow fast and
simple operation.
The user interface is designed to minimize the time invested in getting
familiar with the instrument. After familiarization, the instrument supports
quick setups of signals. This leaves you free to concentrate on the
measurement task and testing of the DUT.
