Keysight 81150A - Carrier Frequency

Features and Functions
81150A and 81160A User’s Guide 183
3.7.3 Carrier Frequency
Introduction
The maximum carrier frequency depends on the function selected as shown
below. The default is 1 MHz for all functions.
Function
Minimum Frequency
Maximum Frequency
Sine
1 Hz
81150A: 240 MHz
81160A: 500 MHz
Square
1 Hz
81150A: 120 MHz
81160A: 330 MHz
Ramp
1 Hz
81150A: 5 MHz
81160A: 20 MHz
Arbs
1 Hz
81150A: 120 MHz
81160A: 330 MHz
Pattern
1 Hz
81150A: 120 MHz
81160A-330: 330 MHz
81160A-660: 660 MHz
81150A and 81160A: 10
MHz for external patterns
Front-Panel
Operation
To set the carrier frequency, press the Frequency softkey for the selected
function. Then use the knob or numeric keypad to enter the desired
frequency.
Remote Interface
Operation
:FREQuency[1|2] {<frequency>|MINimum|MAXimum}
You can also use the APPLy command to select the function, frequency,
amplitude, and offset with a single command.
