Keysight 81160A - Output Source Impedance

Features and Functions
81150A and 81160A User’s Guide 111
3.2.7 Output Source Impedance
Introduction
81150A: An impedance of 50 , 5  is selectable.
81160A: The output source impedance is 50  fix.
Source Impedance
Characteristics
The source impedance is stored in volatile memory; it is set to 50  (default
value), when power has been off or after a remote interface reset (assuming
Power On is set to “default”).
Front Panel
Operation
Output Impedance can be found on the Pulse, Sine, Square, Ramp, Arb,
Noise, DC screens.
Remote Interface
Operation
The following function is used to configure the output source impedance
remotely (81150A, only):
:OUTput[1|2]:IMPedance {<ohms>|MINimum|MAXimum}
