Keysight 81160A - Amplifier Type Selection

Features and Functions
81150A and 81160A User’s Guide 113
3.2.9 Amplifier Type Selection
The Amplifier Type Selection applies to the 81150A only. The 81160A has
one type of amplifier. See the data sheet for the output amplifier
specifications of the 81160A.
Introduction
There are two different amplifiers available for each channel inside the
81150A. One amplifier is optimized for high bandwidth, but provides a
smaller output voltage window. The second one is optimized for high output
voltage, but has a lower bandwidth.
Max. Bandwidth
Max. Amplitude
Max. Frequency
240 MHz
50 MHz
Max. Amplitude
(50 into 50)
5 Vpp (if frequency
is  120 MHz)
10 Vpp
3 Vpp (if frequency
is  120 MHz)
Voltage Window
(50 into 50)
5 V
10 V
Min. Transition Time
2.5 ns
7.5 ns
Min. Width
4.1 ns
10 ns
The amplifier selection applies additional limitations to available voltage
range, frequency, transition time, and width/duty cycle.
Front Panel
Operation
Press the key and then select the Output Setup softkey.
Press the Amplifier Type and use the knob or the softkey to set the desired
value.
Remote Interface
Operation
:OUTPut[1|2]:ROUTe {HIVoltage|HIBandwith}
