3.4.1 Pulse Period
Introduction
The pulse period defines the time between two consecutive pulses from the
start of the leading edge to the start of the next leading edge.
It can be set as either period or frequency.
The pulse period will be ignored for triggered pulses.
Pulse Period
Characteristics
 81150A: Pulse period limits: 8.33 ns to 1000000 s.
81160A: Pulse period limits: 3.03 ns to 1000000 s.
 Pulse frequency limits: 1 Hz to 120 MHz for 81150A. 1 Hz to
330 MHz for 81160A
 The default value is 1 s/1MHz.
 The specified period must be greater than the sum of the pulse width
and the edge time as shown below.
Period  Pulse Width + (1.6x Edge Time)
Front-Panel
Operation
After selecting the pulse function, press the Frequency softkey again to
toggle to the Period softkey. Then use the knob or numeric keypad to enter
the desired pulse period.
Remote Interface
Operation
The following function is used to configure the Pulse Period remotely:
:PULSe:PERiod[1|2] {<seconds>|MINimum|MAXimum}
:PULSe:FREQuency[1|2]{<frequency>|MINimum|
MAXimum}
