Features and Functions
81150A and 81160A User’s Guide 209
3.10.2 Carrier Waveform Shape
FSK carrier shape: Sine, Square, Ramp, or Arbitrary waveform.
The default is Sine. You cannot use pulse, noise, or dc as the carrier
waveform.
Steps:
Press any of the front-panel function keys except or .
For arbitrary waveforms, press and then press More key.
Press the Select Waveform softkey to select the active waveform.
Remote Interface
Operation
:FUNCtion[1|2] {SINusoid|SQUare|RAMP|USER}
You can also use the APPLy command to select the function, frequency,
amplitude, and offset with a single command.
