2.22 Outputting a Stored Arbitrary Waveform
Introduction
There are seven built-in arbitrary waveforms stored in the non-volatile
memory.
The following steps show you how to output the built-in “exponential fall”
waveform from the front panel.
Select the arbitrary
waveform function
When you press the key to select the arbitrary waveform function,
the 81150A / 81160A displays the currently used waveform in the textual
screens indicating which waveform is currently selected (the default is
“exponential rise”).
Select the active
waveform
Steps:
 Press the MORE softkey twice.
 This brings you to a screen which has Select Waveform softkey on
it.
 Press the Select Waveform softkey and select from the given
options. Choose the desired waveform and press select. Confirm your
choice by pressing Yes.
The 81150A / 81160A has a graphical browser to select the waveform to be
used. This waveform can either be a predefined one, or a user defined one
(from VOLATILE memory or a stored waveform from NON-VOLATILE
memory). It is also possible to import a waveform from a USB stick into
VOLATILE memory.
