Front-Panel Menu Operation
81150A and 81160A User’s Guide 39
Ramp Wave
Characteristics
A ramp is defined by the following parameters:
 Amplitude/Offset or High/Low Level
 Period or Frequency
 Delay in seconds
 Delay in percent of period
 Delay as phase in degree
 Symmetry point in percent of period.
 Polarity
 Source Impedance
 Load Impedance
Noise Wave
Characteristics
Noise is defined by the following parameters:
 Amplitude/Offset or High/Low Level
 Probability Density Function (PDF)
 Source Impedance
 Load Impedance
Arbitrary Wave
Characteristics
Arbitrary waveforms are defined by the following parameters:
 Amplitude/Offset or High/Low Level
 Period or Frequency
 Delay in seconds
 Delay in percent of period
 Delay as phase in degree
 Source Impedance
 Load Impedance
81150A: Arbitrary waveforms can have up to 512k samples. The local
waveform editor allows to create and edit waveforms with up to 16k
samples.
81160A: Arbitrary waveforms can have up to 256k samples (1 channel) /
128k samples (2 channels). The local waveform editor allows to create and
edit waveforms with up to 16k samples.
