14 PWR-01
Connecting the Power Cord
This product conforms to IEC Overvoltage Category II (energy-consuming equipment that is
supplied from a fixed installation).
400W model/ 800W model
1
Check that the AC power line meets the nominal input rating of the prod-
uct.
The product can receive a nominal line voltage in the range of 100 Vac to 240 Vac at
50 Hz or 60 Hz.
2
Check that the POWER switch is turned off.
3
Connect the power cord to the AC inlet on the rear panel.
4
Insert the power plug into a grounded outlet.
Risk of electric shock.
• This product conforms to IEC Safety Class I (equipment that has a protective con-
ductor terminal). Be sure to earth ground the product to prevent electric shock.
• The product is grounded through the power cord ground wire. Connect the protec-
tive conductor terminal to earth ground.
• Use the included power cord to connect to the AC line.
If the supplied power cord cannot be used because the rated voltage or the plug shape is
incompatible, have a qualified engineer select an appropriate power cord that is 3 m or less
in length.
• The power cord with a plug can be used to disconnect the product from the AC power line
in an emergency. Connect the plug to an easily accessible power outlet so that the plug can
be removed from the outlet at any time. Be sure to provide adequate clearance around the
power outlet.
• Do not use the dedicated power cord with other instruments.
