136 PWR-01
A
Factory Default Settings
If you hold down LOCAL and PWR DSPL and turn the POWER switch on, the PWR-01 will be
initialized to its factory default settings.
After the LEDs on the front panel light, the voltmeter displays “
INIT,” and the PWR-01 is set
to factory default settings.
The factory default settings are shown below.
Basic settings
Basic item Description
Output voltage 0 V
Output current 105 % of the rated output current
OVP (overvoltage protection) 112 % of the rated output voltage
OCP (overcurrent protection) 112 % of the rated output current
UVL (undervoltage limit) 0 V
Preset memory values A, B, C Factory default settings
(Output voltage, output current, OVP, OCP, UVL)
CONFIG shortcut
SC1, SC2, SC3
No CONFIG parameter registration
